Automatic Ginger Juice Vacuum Concentration Machine is used to concentrate ginger juice and remove the water. so the ginger become thick. These ginger juice can be used for following ginger juice making or ginger powder spray dryer. It is especially suitable for low-temperature vacuum concentration of heat-sensitive substances. It can carry out continuous sterilization and concentration. The concentrator is especially applicable to the concentration of heat-sensitive substances like milk as the heat up time is short and the evaporation temperature is low, which seldom affects the color, flavor or nutrient components of the products.
Table of Contents
Structure Introduction of Ginger Juice Vacuum Concentration Machine
- The equipment consists of a heating chamber, separator, defoamer, steam separator, condenser, cooler, liquid storage barrel, circulating pipe and other components. The whole equipment is made of high-quality stainless steel materials.
- The inner part of the heating chamber is the column tube type. After the shell is connected with the steam, the liquid inside the column tube is heated. The chamber also equipped with pressure gauges and safety valves to ensure production safety.
- The front of the separation chamber is provided with a visual lens for the operator to observe the situation of liquid evaporation. The rear manhole is convenient to clean when changing the breed. It has a thermometer and a vacuum meter that can observe and master the temperature of the liquid in the evaporating chamber and the vacuum degree when evaporating with pressure.
Advantage Feature of Vacuum Ginger Juice Concentrator
- Energy-saving, taking SJN-1000B type for calculating, for a year, approximately 5000 tons of steam, and cooling water of hundreds of thousands of tons can be saved, thus, cost of at least 40,000 USD is saved.
- The concentrator adopts external heating natural cycling mode and negative pressure evaporating mode, with instant evaporation and great concentrated specific gravity up to 1.3 (common soaked Chinese medicine creams). Open boiler is not needed to reclaim creams.
- The concentrator adopts tri-effect simultaneous evaporation and uses second-time steam repetitively. Therefore, the energy can be saved by 70% when compared with a single-effect concentrator. Within a year, the investment saved can be up to the total investment on the concentrator.
- All parts of the vacuum concentrator contacting with materials are made of (AISI304) stainless steel according to requirements in laws related to medicines and foods, and requirements of cGMP. It has a nice appearance. And heater and evaporator have external heat preservation layers. The heat preservation layers are made of stainless steel and polished with semi-luster for a nice appearance in the layout of the workshop.
Parameter Table of Ginger Juice Vacuum Concentration Machine
Model | RM-SJ500 | RM-SJ1000 | RM-SJ1500 | RM-SJ2000 | RM-SJ3000 | |
Capacity | ≥500 | ≥1000 | ≥1500 | ≥2000 | ≥3000 | |
Steam consumption | ≤275 | ≤550 | ≤825 | ≤1100 | ≤1650 | |
Coolwater consumption | 5 | 10 | 15 | 15 | 25 | |
Vacuum exhaust volume | 150 | 240 | 375 | 480 | 600 | |
Heating Area(m3) | 8 | 12.5 | 18.5 | 25 | 37 | |
Condensation Area(m3) | 16 | 20 | 26 | 32 | 38 | |
Dimension | L | 4000 | 5000 | 5500 | 6500 | 6800 |
W | 1500 | 1700 | 1800 | 2000 | 2000 | |
H | 3300 | 3500 | 4000 | 4200 | 4500 | |
Evaporation Temperature | First | 80-90 | 80-90 | 80-90 | 80-90 | 80-90 |
Evaporation Temperature | Second | 55-70 | 55-70 | 55-70 | 55-70 | 55-70 |
Design Pressure | 0.09 | 0.09 | 0.09 | 0.09 | 0.09 | |
Degree of Vacuum | First | -0.04 | -0.04 | -0.04 | -0.04 | -0.04 |
Second | -0.06 | -0.06 | -0.06 | -0.06 | -0.06 | |
Concentration Ratio | 1.1-1.3 | 1.1-1.3 | 1.1-1.3 | 1.1-1.3 | 1.1-1.3 |
Working Video of Ginger Juice Vacuum Concentration Machine
